| 애플리케이션: | 지게차 리튬 배터리 | 모델: | ESCH 48V 200A |
|---|---|---|---|
| 전반적인 차원: | 607*281.4*511.6mm | 최대 출력 전류(A): | 200 |
| 출력 전력(W): | 13000 |
Product Description
The ESCH forklift battery charger typically refers to an industrial charger used to replenish the energy in forklift batteries. These chargers are often designed for heavy-duty environments, aiming to ensure optimal performance, efficiency, and longevity of forklift batteries.
Product Catalog
| Model | ESCH 48V 200A | |
| Overall dimension | 607*281.4*511.6mm | |
| Maximum output current(A) | 200 | |
| Output power(W) | 13000 | |
| Input Power Supply | 380V土15% Three phases Four-wire | |
| Maximum Output Voltage(VDC) | 65 | |
| Compatible Battery Specification | 48V 400-600Ah lithium battery | |
| Maximum Efficiency | ≥93% | |
| Output Voltage Regulation Accuracy | ±1% | |
| Output Current Regulation Accuracy | ±1% | |
| Operating Temperature | -40°C-50℃ | |
| Vibration Resistance Grade | SAEJ1378 | |
| Cooling Method | Forced Air Cooling | |
| Over Temperature Protection | 70℃ | |
| Input Overvoltage Protection (VAC) | ＞530±10V | |
| Input Undervoltage Protection (VAC) | ＜250±10V | |
| Output Overvoltage Protection (VDC) | 65±5 | |
| Output Overcurrent Protection (A) | >110% of Max Charging Current | |
| Output Short Circuit Protection | When output short-circuited, the charger shuts down automatically; it will self-recover after fault removal. | |
| Battery Reverse Polarity Protection | None | |
