제품 상세 정보:
결제 및 배송 조건:
|
| 유형: | 솔리드 타이어 프레스 머신 | 모델: | TP120 |
|---|---|---|---|
| 용량: | 120tons | 기원: | 중국 |
| 보증: | 액세서리 평생 보증 | 가장 밝은 부분: | 지게차 타이어 프레스 기계, 솔리드 타이어 프레스 기계 |
Product Description
|
Type: |
Solid Tire Press Machine |
Application: |
Forklift Tire Replacement |
|
Model: |
TP120 |
Capacity: |
120Tons |
|
Weight: |
1300kgs |
Size: |
L1600mm*W800mm*H1650mm |
|
Brand: |
LAKER |
Motor: |
4KW |
|
Max. Tyre |
15Inches |
Cylinder Max. Stroke |
400mm |
Product Introduction
1.2MN solid tyre pressing machine is a special equipment for solid tire loading and unloading,
It can also apply to the tyres below 15 ".
This machine is a frame type structure.The hydraulic cylinder is located above the piston movement from top to bottom, the department. Platform, fixed on the piston rod and spherical pressure box, firm structure, is made of high-quality materials carefully assembled, so good performance. With the electric control box independent.
The hydraulic system of the machine consists of hydraulic system and hydraulic system of the auxiliary machine. This machine hydraulic system is composed of the high-pressure pump, solenoid valve, pressure relief valve, check valve, pressure indicator and oil cylinder.
High pressure relief valve is the oil pressure setting of high pressure pump, its maximum setting value is 12MPa.
Product Features
Product Display
Operator Safety
With the multiple features of our presses which are both standard and optional, we know that our hydraulic presses are not only good, they are operator friendly. We offer a front security guard which increases operator safety, important to us and to your business. Our strict adherence to quality standards ensures sound, safe and reliable machinery.
